LWP160/45-E High pressure water pump for cooling and cleaning drill pipes
LWP160/45-E High pressure water pump is used for cooling and cleaning drill pipes in drilling projects. We can supply you with a high-quality high-pressure water pump from a China factory.
LWP160/45-E
18.5KW
645r/min
160L/min@45bar
1340×750×1150mm
355Kg
Introduction
Product Details
Technical data
Cases
Inquiry
Description

The primary application of the LWP160/45-E High pressure water pump lies in the cooling and cleansing of drill pipes. Its fundamental function involves the conversion of regular water into high-pressure, low-flow water using a specialized high-pressure water pump. Subsequently, this pressurized water is conveyed through the high-pressure pipeline to reach the high-pressure nozzle with a specific energy level.

high pressure water pump structure

The nozzles within the system are designed to convert high-pressure, low-flow water into low-pressure, high-flow jets. This mechanism operates on the principle that when the impact force generated by the high-pressure water jet exceeds the adhesion between surface dirt and the object, it effectively dislodges and eliminates the dirt, thereby achieving the goal of surface cleansing.

water pump structure
high pressure water pump manufacturer
high pressure water pump manufacturer

Application
LWP160/45-E High pressure water pump is specifically designed for cooling and cleaning drill pipes, it effectively removes debris, mud, and residues, maintaining optimal drilling performance.

high pressure water pump exporter
high pressure water pump factory
high pressure water pump for drilling rig
Features
  1. Featuring a compact structure.
  2. User-friendly operation and simplified maintenance.
  3. Comes equipped with a safety valve.
  4. Minimal spare parts requirement ensures cost-effective maintenance.
  5. Offers multiple discharge port diameters for versatility.
  6. Includes a flameproof electric cabinet, boasting an IP56 protection grade.
  7. Certified with CE and ISO credentials, ensuring quality standards are met.

  1. high pressure water pump for salehigh pressure water pump made in China
Product Details
Accumulator
Electrical control box
Lifting ring
18.5KW motor
Universal wheel
Water pump
Technical Parameters
Technical Data
Name Data
Model LWP160/45-E
Power 18.5KW
Pump speed 645 r/min
Output 160L/min@45bar
Suction port diameter DN65
Discharge port diameter DN20, DN25
Power supply AC three-phase 380V, 50Hz
Dimension 1340×750×1150mm
Weight 355Kg
Note: We can customize according to your requirements.
